Three Beam Coupling: 3mm x 3mm Bores
Three Beam Coupling, Clamp, 9mm OD, 3mm x 3mm Bores
Price Each:
$22.0352
Total Price:
$34.4300
Quantity:
Add to Cart
1 at $34.4300 each
2-4 at $32.7085 each
5-9 at $31.5035 each
10-24 at $29.7820 each
25-49 at $28.0605 each
50-99 at $26.5111 each
100-249 at $24.7896 each
250+ at $22.0352 each
To
$22.0352
725.09.1414 Specifications:
Unit System: metric
Bore B1: 3mm
Bore B2: 3mm
Outside Diameter: 0.400 in.
Type: Beam
Material: Aluminum
Bore Tolerance: +.0012 in.
Backlash: Torsionally Rigid
Fastening Method: Clamp
Minimum Order Qty.: 1
Max RPM: 3500
Torsion Stiff (Lb*in/Deg): 0.834
Electrical Isolation: No
Length Extended: N/A
Max Angular Offset: 3 degrees
Max Axial Offset: 0.000 in.
Mass: 2g
Max Torque: 3.50 lb-in
Temperature Range: -40°F to +248°F
HP @ 1750 RPM: N/A
Typ Air Gap: N/A
725.09.1414 Product Files:
Catalog Page.pdf
