High Speed In-Line Spur Gear Box > Inline Spur Gear Reducer - 64:1 Ratio

Inline Spur Gear Reducer - 64:1 Ratio

Part Number: XJ65-64

Inline Spur Gear Reducer, 6mm to 8mm Bore Input (specify), 6mm Output Shaft, 64:1 Ratio
Price Each:
23.64
Quantity:
Total Price:
$623.64
XJ65-64 Specifications:
Ratio 64:1
Output Shaft Diameter 6mm
Input Bore Diameter Input bore, tapped holes & register must be specified when ordering. Contact Ondrives engineers for assistance.
Material Delrin/Aluminum/Steel
Efficiency @ 1000 RPM 0.88
Box Length 50mm
Input Keyway Height N/A
Use Output Key KK2-14
Housing Material Delrin/Aluminum
Input Key Length N/A
Output Key Width 2mm
Box Diameter 63mm
Shaft Output Type In-Line
Output Key Height 2mm
Output Key Length 14mm
XJ65-64 Product Files:
• Catalog Page.pdf
View CAD Model View CAD Library
